Sugatsune | ESR-9 Series | 12in | Stainless Steel Drawer Slide

  • Sugatsune | ESR-9 Series | Stainless Steel Drawer Slide
  • Sugatsune | ESR-9 Series | Stainless Steel Drawer Slide

Hover over image to zoom in

SKU: ESR-9-12

  • Original Sugatsune Hardware

Back
$45.90
Step 1 - Select Length
$45.90
 per piece

Our return policy

Quantity Pricing

1 - 19
20 - 59
Savings: 9%		60 +
Savings: 17%
$45.90$41.36$37.92

Available To Order

Back
BrandSugatsune
CertificationRoHS 3
Dynamic Load RatingSide Mount: 11.02 lbs (5 kg) per pair
FinishPlain
Height0.44 in (11.3 mm)
IncludesMounting plate included
LengthLength of Item when open: 12 in (304.8 mm) | Length of Item when closed: 12 in (304.8 mm)
Material304 Stainless Steel
Mounting HardwareBinding Head 4mm or #8,Pan Head 4mm or #8,Truss Head 4mm or #8
NotesThis hardware has not been evaluated for use in applications where magnetic permeability is an issue, such as MRI rooms
Product Weight.639 lbs per piece
TypeLinear Guide | Side Mount | Non-Handed
Width2.38 in (60.4 mm)
